Vibratory pile driver for excavator is a hydraulic attachment designed to mount on excavators, backhoes, or similar machinery. It uses high-frequency vibrations to liquefy the soil around a pile, drastically reducing friction and allowing the pile to be driven or extracted with minimal effort. Different from impact hammers, vibratory drivers operate quietly and smoothly, making them ideal for environments where noise and vibration are concerns.
Parameters of the Vibratory Pile Driver for Excavator
| Model | YG-45 | YG-80 | YG-125 |
| Suitable Excavator | 12–18T | 20–27T | 30–40T |
| Working Flow Rate | 113L | 200L | 260L |
| Maximum Working Pressure | 35Mpa | 35Mpa | 35Mpa |
| Maximum Vibration Force | 343KN | 450KN | 695KN |
| Impact Frequency | 2500rpm | 2500rpm | 2080rpm |
| Maximum Pile Extraction Force | 120KN | 120KN | 168KN |
| Outer Diameter Of Pipe Piles | ≤300mm | ≤300mm | ≤300mm |
| Machine Weight | 1350KG | 2300KG | 2800KG |
| Dimension | 2306*1268*680mm | 2306*1268*680mm | 2610*1616*746mm |
Features of Our Excavator-Mounted Pile Driver
- Strong Excitation Force
Equipped with a high-frequency vibration motor, vibratory pile driver for excavator can penetrate dense soil and tough substrates with ease. - Hydraulic Operation System
Advanced hydraulic systems ensure smooth operation, better control, and minimal maintenance needs. - Flexible Clamping Mechanism
The adaptable clamping head fits various pile types, including sheet piles, steel pipes, and concrete piles. - Noise and Vibration Control
Designed to reduce noise and structural vibration, making it ideal for urban and sensitive environments.
Applications for Vibratory Pile Driver for Excavator
- Foundation Systems: Retaining walls, cofferdams, and basement walls.
- Infrastructure Projects: Bridge abutments, culverts, noise barriers, slope stabilization.
- Marine & Waterfront: Seawalls, docks, jetties, flood defense systems.
- Utility Installation: Trench shoring, pole foundations.
- Environmental Barriers: Cut-off walls for contamination control.
- Temporary Works: Fast installation and extraction for temporary support.
Benefits of Using YG Excavator Pile Driver
- Cost-Effective
Turn your existing excavator into a powerful vibratory pile driver for excavator without investing in separate heavy equipment. - Time-Saving
Drives and extracts piles quickly, reducing labor costs and overall project time. - Versatile Use
Suitable for a wide variety of projects and compatible with different pile types and soil conditions.
Why Choose a Vibratory Pile Driver Attachment for Your Excavator?
- Unmatched Speed & Efficiency: Drive piles significantly faster than traditional impact hammers, drastically reducing project timelines and labor costs. Ideal for large-scale projects.
- Reduced Noise & Vibration: A quieter solution compared to impact hammers, minimizing disruption in urban areas, near sensitive structures, and improving worksite safety/compliance.
- Minimized Soil Disturbance: Vibratory methods cause less lateral soil displacement than impact driving, protecting nearby foundations and underground utilities.
- Cost-Effective Operation: Lower fuel consumption compared to diesel hammers and reduced wear-and-tear translate to lower operating costs per pile.
