Small skid loader, also known as a skid steer loader, is a compact, engine-powered machine with lift arms that can attach to a variety of labor-saving tools or attachments. Its small size and maneuverability make it ideal for working in tight spaces where larger equipment cannot fit. The term “skid” refers to the way these machines turn; the wheels or tracks on each side of the loader are locked together and can only move in the same direction, causing the machine to skid or drag its wheels as it turns.
Technical Data of Small Skid Loader
| Model | YGW45 | YGW65 | YGT50 | YGT65 |
| Operating load (kg) | 700 | 1050 | 700 | 1000 |
| Max Speed（km/h） | 10 | 10 | 10 | 12 |
| Rated flux (L/min) | 80 | 89 | 80 | 89 |
| Rated power (kw) | 36.7 | 55 | 45 | 55 |
| Fuel tank capacity (L) | 70 | 75 | 50 | 90 |
| Self-weight bucket (kg) | 3766 | 4498 | 4074 | 5024 |
| Bucket capacity (m³) | 0.4 | 0.5 | 0.4 | 0.5 |
| Overall operating height (mm) | 3560 | 3850 | 3660 | 3900 |
| Height to bucket hinge pin (mm) | 2765 | 3020 | 2730 | 2970 |
| Height to top of cab (mm) | 2230 | 2295 | 2349 | 2409 |
| Height to bottom of level bucket(mm) | 2909 | 2862 | 2500 | 2790 |
| Without bucket length（mm） | 2325 | 2527 | 2170 | 2450 |
| Overall length with bucket(mm) | 3276 | 3428 | 3150 | 3400 |
| Dumping angle at maximum height(° ) | 37.5 | 32 | 40 | 40 |
| Dumping height(mm) | 2342 | 2410 | 1990 | 2270 |
| Dumping reach(mm) | 550 | 850 | 1040 | 1120 |
| Rollback of bucket on ground(° ) | 20.5 | 23 | 30 | 30 |
| Rollback of bucket at full height(° ) | 96.5 | 95 | 100 | 100 |
| Wheelbase(mm) | 991 | 1074 | 1230 | 1500 |
| Ground clearance(mm) | 185 | 205 | 230 | 200 |
| Angle of departure(° ) | 20 | 20 | 18.5 | 18.5 |
| Front turning radius without bucket(mm) | 1188 | 1320.5 | 1064 | 1230 |
| Front tuning radius(mm) | 2030 | 2095 | 1825 | 2010 |
| Rear tuning radius(mm) | 1630 | 1680 | 1264 | 1720 |
| Rear axle to bumper (mm) | 929 | 1057 | 590 | 730 |
| Tread width (mm) | 1462.5 | 1498 | 1022 | 1482 |
| Width (mm) | 1726.5 | 1805 | 1422 | 1782 |
| Bucket width (mm) | 1727 | 1828 | 1727 | 1828 |
Features of Mini Skid Loader
- Compact Size
Small skid loaders are designed to be compact and lightweight, allowing them to navigate through narrow doorways, tight alleys, and congested job sites with ease. This makes them perfect for indoor renovation projects, landscaping in residential areas, and agricultural tasks in small farms. - Versatility
One of the most significant advantages of small skid steer loaders is their versatility. With a wide range of attachments available, such as buckets, forks, augers, trenchers, and more, these machines can perform a multitude of functions, including digging, lifting, grading, and material handling. This eliminates the need for multiple specialized machines, saving you time and money. - Maneuverability
The skid-steer design provides exceptional maneuverability, allowing the operator to make sharp turns and navigate around obstacles with precision. This is particularly useful in confined spaces where traditional loaders or excavators would struggle to operate.
Why Choose a Small Skid Loader?
- Superior Maneuverability
Mini skid steer loaders can turn within their own footprint, making them ideal for narrow alleys, indoor operations, or urban construction zones. Their zero-radius turning capability is a huge benefit in congested areas. - Versatile Attachments
Whether you need a bucket, auger, pallet forks, sweeper, or snow blower, small skid steer loaders can be equipped with a variety of attachments. This versatility allows you to perform multiple tasks with a single machine. - Cost-Efficient and Fuel-Saving
Compared to larger models, a small skid loader consumes less fuel, requires less maintenance, and has a lower initial purchase price, making it a great investment for small businesses or part-time operators.
Small Skid Steer Loader Applications
Small skid loaders are used across a wide range of industries due to their flexibility and power. Common applications include:
Construction: Loading and unloading materials, grading, and site preparation
Landscaping: Moving soil, mulch, and stones; digging and trenching
Agriculture: Cleaning barns, feeding livestock, transporting feed
Snow Removal: Clearing driveways and sidewalks with a snow blower or blade attachments
Demolition: Handling debris, light breaking tasks with hydraulic hammers
